1054/F67C3 reagent-free filtration unit

The reagent-free filtration unit removes dissolved iron, manganese and hydrogen sulfide from water, along with turbidity and color, bringing the water to the required standards. Inside: a fiberglass housing laminated with polyethylene on the inside, an automatic control valve, granular filter media, a supporting gravel layer, and a drainage-distribution system.

The media oxidizes dissolved iron and manganese directly: passing through it, they convert to an insoluble form and precipitate as sediment, which is retained within the media bed. No reagents are needed for this — the accumulated sediment is flushed to drain by backwash, which also restores the filtering capacity of the media. The frequency of backwashing depends on the combined content of iron, manganese and hydrogen sulfide in the source water. Housings from 8 to 13 inches are fitted with 3/4″ and 1″ Runxin valves rated up to 4.5 m³/h, all top-mounted.

Design 1054/F67C3: 10×54″ housing, automatic Runxin F67C3 valve with water meter, up to 4.5 m³/h, 1″ connection, top mounting. The valve is rated for filtration — backwash of the media without reagent. Weight 11.89 kg.

Configuration within the line: vessel size 1054 (10×54″) with control valve Runxin F67C3. On the same vessel size 1054 (10×54″) the line also offers Runxin F71P, Runxin F67G, Runxin F71Q1, Runxin F67C and others. The same control valve Runxin F67C3 is fitted on 0844, 1344, 1252, 1248 and others. Among the units on vessel size 1054 (10×54″) this is the only one with purpose — filtration.

On vessel size 1054 the closest alternatives to Runxin F67C3 are Runxin F71P (valve capacity up to 2.0 m³/h instead of up to 4.5 m³/h, connection 3/4" instead of 1", weight 11.4 kg instead of 11.89 kg), Runxin F67G (valve capacity up to 4 m³/h instead of up to 4.5 m³/h, weight 12.22 kg instead of 11.89 kg) and Runxin F71Q1 (valve capacity up to 2.0 m³/h instead of up to 4.5 m³/h, connection 3/4" instead of 1", weight 15.06 kg instead of 11.89 kg).
